Welcome to my Kiribati 36 DIY build journey. A 36′ Aluminium ‘Bluewater’ sailboat with twin rudders and a retractable keel. After completing a global circumnavigation on two wheels (See: Blog | YouTube) I now set my sights on doing the same by water. My hope is that the build, cost tracking and lessons learned will aid aspiring boat builders in their own quest. Please know the following:
- I have no affiliation with the company selling the boat plans, in other words, my words are my own. I am however affiliated with Google AdWords in the hope that any revenue made will assist towards the completion of this project.
- In the event of me deviating from the original build plans, adding my own parts, or amending parts then this is highlighted in the articles with ‘** Note‘.
- An up-to-date parts/article Index (including total expenditure) can be found: HERE
- Feel free to ask question via this blog, YouTube comments, or email: kiribati36 @ modularhippo.com – My aim is to respond to all questions within 24 hours.
Cost To Date: £23,657.45->£27,448.12 | $30,484.84->$35,511.12
Index
| Build Progress | Cost Tracking | Lessons Learned | Related Links |
Build Progress
Cost Tracking
Breakdown (when applicable):
Parts/Material – Any raw material that I needed, or any ready made parts.
External Labour – External help with machining, milling or welding.
Tools & Misc. – Cost related to project, but not part of physical boat itself.
Category Breakdown – Cost Tracking per Category in £|$|%.
| PARTS/MATERIAL | (GBP) | (USD) |
| 1 x Keel Box Side Left – L19B-12 1083x412x12mm AL-5083-10 – (Parts & Material) | £147.13 | (≈$194.98) |
| 1 x Keel Box Side Right – L21B-12 1083x412x12mm AL-5083-10 – (Parts & Material) | £141.74 | (≈$187.83) |
| 1 x Round Keel Side Lid – L20-10 Ø100x10mm AL-5083-10 – (Parts & Material) | £6.02 | (≈$7.98) |
| 8 x M6 22mm A4 SS Allen head bolts (for keel box lid) – (Parts & Material) | £3.66 | (≈$4.85) |
| 2 x Keel Pivot Holder Support – B08-8 788x96x8mm AL-5083-8 – (Parts & Material) | £38.25 | (≈$50.69) |
| 1 x 130×130 gasket material (2 mm thickness) – (Parts & Material) | £8.18 | (≈$10.84) |
| 8 x M6 nylon washers – (Parts & Material) | £2.71 | (≈$3.59) |
| 8 x M6 A4 SS washers – (Parts & Material) | £4.93 | (≈$6.53) |
| 1 x (AL-5083-10) – Keel Box Bow (head) Short side – L18-10 – (Parts & Material) | £95.68 | (≈$126.79) |
| 2 x (AL-5083-10) – Two Small Keel Box sides – L22-10 – (Parts & Material) | £82.06 | (≈$108.75) |
| 2 x (AL-5083-10) – Cradled shelf for Pivot Stop Support Rod) – L30-10 – (Parts & Material) | £21.39 | (≈$28.35) |
| 4 x (AL-5083-10) – (Cradled sides for 2 x shelf for Pivot Stop Support Rod) – L31-10 – (Parts & Material) | £14.73 | (≈$19.52) |
| 2 x L26-10mm (Aluminum 5083 – Starboard & port side keelbox ledge lip) – (Parts & Material) | £159.70 | (≈$211.63) |
| 1 x L27-10mm Aluminum 5083 – (Upper aft keel box ledge lip) – (Parts & Material) | £5.19 | (≈$6.88) |
| 1 x L24-10mm (Aluminum 5083 – Lower aft keel box box short side) – (Parts & Material) | £22.56 | (≈$29.90) |
| 1 x L25-10mm (Aluminum 5083 – Upper aft keel box box short side) – (Parts & Material) | £43.98 | (≈$58.28) |
| 2 x Port & Starboard Keel box sides – (Parts & Material) | £991.84 | (≈$1,314.38) |
| 1 x Keel Box Lid – 6 mm Aluminium 5083 – L28-6 (Wider lid) – (Parts & Material) | £66.32 | (≈$87.89) |
| 1 x Keel Box Lid – 6 mm Aluminium 5083 – L29-6 (Thin Lid) – (Parts & Material) | £48.55 | (≈$64.34) |
| 50 x M6 x 30mm Allen Key Bolt A4 Marine Grade SS – (Parts & Material) | £8.57 | (≈$11.36) |
| 100 x M6 6mm / 12mm / 1.2mm White Plastic Spacers – (Parts & Material) | £3.79 | (≈$5.02) |
| 100 x M6 Marine Grade A4 Stainless FORM A Flat Washers 316 – (Parts & Material) | £7.06 | (≈$9.36) |
| 50 x M6 Stainless Steel A4 Marine Grade SS Nyloc Nuts – (Parts & Material) | £5.70 | (≈$7.55) |
| 50 x Shoulder Washers – (Parts & Material) | £15.28 | (≈$20.25) |
| Neoprene Rubber Sheet / Solid Black Smooth (Seal for Lids) – (Parts & Material) | £38.43 | (≈$50.93) |
| 300mm M12 Threaded rod to be used to mark out centre of lock up pin – (Parts & Material) | £8.14 | (≈$10.79) |
| 2 x Nuova Rade round Inspection Hatch – 133mm – (Parts & Material) | £21.40 | (≈$28.36) |
| 12 x A4 Stainless Steel Marine Grade Form G Washers Flat Washer M3 – (Parts & Material) | £4.61 | (≈$6.10) |
| 20 x Nyloc Nylon Lock Nuts M3 A4 Marine Stainless Steel – (Parts & Material) | £3.59 | (≈$4.76) |
| 20 x M3 M4 Stainless Countersunk Socket Screw Allen Key Bolt DIN7991 – (Parts & Material) | £4.00 | (≈$5.30) |
| 20 x Nylon Plastic Bearings Bushings Shoulder Washers M3 – (Parts & Material) | £8.18 | (≈$10.84) |
| 6mm AL 5083 Spacer Plate for the 8 Sheaves M8 Bolts – (Parts & Material) | £7.25 | (≈$9.61) |
| 1 x 4.4mm Ground Drill Bit for drilling holes for Inspection Hatches – (Material) | £5.45 | (≈$7.21) |
| 1 x 40mm ABS Male/Female Waste Coupler – (Material) | £3.58 | (≈$4.74) |
| 1 x New Waste Pipe Square (UK Standard) Note: Got this for free from curt – (Material) | £0 | (≈$0) |
| (Part 24) | Keel Housing | £2049.65 | (≈$2716.18) |
| EXTERNAL LABOUR | (GBP) | (USD) |
| Tacking the Upper Bearing Assembly to the Keel Housing (later had to be undone as was done prematurely (parts need chafing in areas for lower weld) – (External Labour) | £30 | (≈$39.75) |
| Welding Upper Bearing Assembly and supports to the Keel Housing – (External Labour) | £280 | (≈$371.05) |
| Welding 2 x Cradled sides for 2 x shelf for Pivot Stop Support Rod- (External Labour) | £20 | (≈$26.50) |
| Welding 2 x Cradled sides shelf for Pivot Stop Support Rod to Keel Box Sides – (External Labour) | £30 | (≈$39.75) |
| Welding 2 x Large Port & Starboard Keel box sides to aft 2 x Short Sides – (External Labour) | £90 | (≈$119.27) |
| Alignment and weld of Keel box end plate and two keel box bearing side plates – (External Labour) | £140 | (≈$185.53) |
| Final Short Side Weld of Upper Bearing Assembly to Keel Housing side – (External Labour) | £30 | (≈$39.75) |
| Lid Holes Welded Closed as new alignment needed – (External Labour) | £30 | (≈$39.75) |
| 1 x Square New Waste Pipe welded to the Lid by Rob – (External Labour) | £30 | (≈$39.75) |
| 1 x Square Strainer Bracket Welded to the Keel-box by Rob – (External Labour) | £30 | (≈$39.75) |
| 2 x Lock Up Pin Plugs Welded to the Keel Box walls by Rob – (External Labour) | £30 | (≈$39.75) |
| 2 x Keel Resting Brackets/Shelves welded to the keel box by Rob – (External Labour) | £30 | (≈$39.75) |
| Merging keel box halves Rob welding – (External Labour) | £160 | (≈$212.03) |
| Lid flange Welding by Rob – (External Labour) | £135 | (≈$178.90) |
| 1 x Keel Box Side Left – L19B-12 1083x412x12mm AL-5083-10 – Laser Cutting | £32.30 | (≈$42.80) |
| 1 x Keel Box Side Right – L21B-12 1083x412x12mm AL-5083-10 – Laser Cutting | £33.25 | (≈$44.07) |
| 1 x Round Keel Side Lid – L20-10 Ø100x10mm AL-5083-10 – Laser Cutting | £1.32 | (≈$1.75) |
| 2 x Keel Pivot Holder Support – B08-8 788x96x8mm AL-5083-8 – Laser Cutting | £7.83 | (≈$10.38) |
| 1 x (AL-5083-10) – Keel Box Bow (head) Short side – L18-10 – Laser Cutting | £26.99 | (≈$35.77) |
| 2 x (AL-5083-10) – Two Small Keel Box sides – L22-10 – Laser Cutting | £21.81 | (≈$28.90) |
| 2 x (AL-5083-10) – Cradled shelf for Pivot Stop Support Rod) – L30-10 – Laser Cutting | £4.69 | (≈$6.22) |
| 4 x (AL-5083-10) – (Cradled sides for 2 x shelf for Pivot Stop Support Rod) – L31-10 – Laser Cutting | £3.91 | (≈$5.19) |
| 2 x L26-10mm (Aluminum 5083 – Starboard & port side keelbox ledge lip) – Laser Cutting | £37.46 | (≈$49.64) |
| 1 x L27-10mm Aluminum 5083 – (Upper aft keel Box ledge lip) – Laser Cutting | £1.22 | (≈$1.63) |
| 1 x L24-10mm (Aluminum 5083 – Lower aft keel box short side) – Laser Cutting | £4.95 | (≈$6.56) |
| 1 x L25-10mm (Aluminum 5083 – Upper aft keel box short side) – Laser Cutting | £9.66 | (≈$12.81) |
| 2 x Port & Starboard Keel box sides – Laser Cutting | £279.75 | (≈$370.72) |
| 1 x Keel Box Lid – 6 mm Aluminium 5083 – L28-6 (Wider lid) – Laser Cutting | £17.63 | (≈$23.36) |
| 1 x Keel Box Lid – 6 mm Aluminium 5083 – L29-6 (Thin Lid) – Laser Cutting | £12.91 | (≈$17.11) |
| 6mm AL 5083 Spacer Plate for the 8 Sheaves M8 Bolts – Laser Cutting | £2.05 | (≈$2.72) |
| (Part 24) | Keel Housing | £1562.73 | (≈$2070.91) |
| TOOLS & MISC. | (GBP) | (USD) |
| 1 x 6 Piece Hollow Punch Set (6mm holes in rubber seal gasket) | £3.70 | (≈$4.96) |
| 1 x Extra Long M6 100 Tap (for cap threads) | £8.11 | (≈$10.88) |
| 2 x 5mm Drills to drill cap holes before thread) | 3 Sanding Disc | 2 x Tarpaulin | £18.43 | (≈$24.73) |
| 1 x Carbide Rotary File Milling Metal Grinding Cutter Burr-Head Drill Bit 6mm-Shank (corner weld sanding) | £4.97 | (≈$6.67) |
| 1 x LARGE 1/2″ DIAMETER OVAL CARBIDE MILLING BURR – 6MM SHANK DIE GRINDER TOOL SE5 (corner weld sanding) | £7.99 | (≈$10.72) |
| 1 x Silverline 260W 13mm Power Belt File Sander + 22 Asstd Grit Belts (corner weld sanding) | £51.99 | (≈$69.75) |
| 56g Tub & Brush expiry 2034 – USS Ultra Tef-Gel-Anti Corrosion Gel | £16.00 | (≈$21.47) |
| Neilsen Step Drill HSS Steel Titanium Cone Bit Hole Metal Cutter Tool 4-42mm | £12.89 | (≈$17.29) |
| Magnetic Digital Angle Finder with Electronic – Laser, Angle Tool BO | £14.88 | (≈$19.96) |
| 2 x Ratchet Straps For Getting Box to Rob for Welding on Trailer. | £13.37 | (≈$17.94) |
| 3 x Tarpaulin (Cover Parts From Weather) | £19.98 | (≈$26.80) |
| 2 x 30m Rope (Tie Down Tarpaulin) | £5.98 | (≈$8.02) |
| (Part 24) | Keel Housing | £178.29 | (≈$239.19) |
| CATEGORY | (GBP) | (USD) | % |
| PARTS/MATERIAL | £2049.65 | (≈$2716.18) | 54.07% |
| EXTERNAL LABOUR | £1562.73 | (≈$2070.91) | 41.23% |
| TOOLS & MISC. | £178.29 | (≈$239.19) | 4.70% |
| TOTAL | £3,790.67 | (≈$5,026.28) | 100% |
Lessons Learned
